Bilstein 5100 3rd Gen Toyota Tacoma Suspension Kit

Manufacturer: Bilstein
SKU: Bil-Taco-5100-3G

Bilstein B8 5100 Front (Ride Height Adjustable) shock absorbers are designed for trucks and SUV’s with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-2 inches of front lift (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.


   ​1st clip = 0″ (stock)
   2nd clip = 0.65″
   3rd clip = 1.1″
   4th clip = 1.55″
   5th clip = 2″ (5th notch not recommended for 4×4 V6/4cyl Access Cab or 4×2 V6 Double Cab 6′ bed)

   Collapsed Length (IN): 17.58
   Extended Length (IN): 22.22
   Collapsed Length (MM): 446.5
   Extended Length (MM): 564.5

Bilstein B8 5100 rear shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B8 5100 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B8 5100 shock absorbers are tuned for each specific application to assure optimal performance is achieved. B8 5100 shock absorbers offer a significant improvement in ride quality, handling, and comfort.

   Collapsed Length (IN): 14.02
   Extended Length (IN): 22.94
   Collapsed Length (MM): 356
   Extended Length (MM): 582.7


  • 24-263108 Front Strut (x2)
  • 24-186728 Rear Shock (x2)


  • 2016-2019 Toyota Tacoma


Products specifications
Attribute nameAttribute value
FitmentToyota 3rd Gen Tacoma (2016-2023)
